DESIGN FEATURES

• Air release component discharges entrapped air in pressurized systems.
• Air & vacuum component admits large volumes of air during system drainage and at water column separation.
• Dynamic design enables high-velocity air discharge while preventing premature closure.
• Simple and reliable structure with small dimensions and lightweight construction.

TECHNICAL CHARACTERISTICS

• Maximum working pressure: PN16
• Working temperature: 0–80 °C
• Powder epoxy coating: 250 µm thickness
• Bonnet gasket: NBR
• Color: RAL 5015
• Fully vulcanized ball: EPDM
