•Number of Outlets: 2 outlets on 180° and 1 pumper outlet.
•Inlet Size: 150 mm (6 Inches).
•Working pressure: 16 Bar
•Test Pressure: 24 Bar.
•KV: < 140.
•Number of Outlets: 2 outlets on 180° and 1 pumper outlet.
•Inlet Size: 150 mm (6 Inches).
•Working pressure: 16 Bar
•Test Pressure: 24 Bar.
•KV: < 140.
| ITEM NO. | PART NUMBER | QTY. | DESC. | Material |
|---|---|---|---|---|
| 1 | SFH30-P01 | 1 | Hydrant Body | Gray/Ductile Cast Iron |
| 2 | LND_P01 | 2 | Land Valve Body | Brass |
| 3 | LND_P03 | 2 | Hose Lock | Brass |
| 4 | LND_P05 | 2 | Gate Disc | EPDM/NBR |
| 5 | Hexagon Nut ISO 4034-M8 – N | 2 | Hex Nut M8 | Galvanized Steel |
| 6 | Washer DIN 125-A 8.4 | 2 | Plain Washer 8.4 mm | Galvanized Steel |
| 7 | LND_P06 | 2 | Handle Wheel | Aluminum |
| 8 | LND_P02 | 2 | Land Valve Head Flange | Brass |
| 9 | LND_P04 | 2 | Power Screw | Brass |
| 10 | SFH30-P02 | 1 | CAP | Brass |
| 11 | SFH30-P03 | 1 | Bronze Nut | Brass |
